Additional information
Product specifications...
| Dimensions: | 48 cm (Width) x 35 cm (Depth) x 20.4 cm (Height) |
|---|---|
| Remote Support: | Software Upgradeable over the Internet (minimum 20Mbps connection required) |
| Output Level: | 1V, 2V, 4V |
| Output Impedance: | 0.4, 7.4, 7.5, 8.2, 8.3, 8.7, 8.82, 9.84, 10, 28.57, 30, 46.15, 50, 66.67, 75, 600 ohms |
| Connections: | 1 Wadax Akasa DC socket (for the optional external Power Supply – Studio PSU), 2 BNC input sockets (for the optional external clock – Studio Clock), 1 Ethernet Socket, 1 pair XLR Analogue Outputs |
| Digital Ouputs: | 1 x SPDIF RCA (32KHz-192KHz, 16-24 bits), 1 x SPDIF BNC (32KHz-192KHz, 16-24 bits), 1 x AES-EBU (32KHz-192KHz, 16-24 bits) |
| Supported Disc Standards: | Red Book (CD), Scarlett Book (SACD) |
| Supported Streaming Services: | Spotify Connect, Tidal Connect, Qobuz Connect, Roon Ready, Audirvana, UPnP Certifications for other services in progress. |
| User Interface: | 5 inch capacitive touch full-colour display 800 × 480 |
| Weight | Net Weight 32Kg, Gross Weight including packaging / pallet 55Kg |
